Parameter	DSP46	Unit
Analog Inputs (single ended)	4
Audio input sensitivity (Waveform: Sine Frequency: 1kHz)	2	Vrms
Max. Input Analog Level (Waveform: Sine Frequency: 1kHz)	2	Vrms
Input Impedance (single ended)	14-20	kΩ
Analog Outputs (single ended)	6
Maximum Output Level (input 2 Vrms, 1kHz, THD+N Ratio <0.05%)	2	Vrms
Source Impedance	0.3	Ω
Conditions: (Waveform: Sine, Generator Level: 2.0Vrms, DC Offset: 0.0V, Frequency: 1kHz, Low-pass Filter: 20kHz, Weighting Filter: A-wt. High-pass Filter: 20Hz)	<0.05	%
Noise Level
(Waveform: Sine, Generator Level: 20mVrms, DC Offset: 0.0V, Frequency: 1kHz, Low-pass Filter: 20kHz, Weighting Filter: A-wt. High-pass Filter: 20Hz)	-92	dBV
Frequency Response
(Generator Level: 1 Vrms, DC Offset: 0.0V, EQ: None, Start Frequency: 20 Hz, Stop Frequency: 20kHz)	Please see Figure *
Signal to Noise Ratio
(Waveform: Sine, Generator Level: 2 Vrms, DC Offset: 0.0V, Frequency: 1 kHz, Low-pass Filter: 20kHz, Weighting Filter: A-wt. High-pass Filter: 20Hz)	99	dB
Crosstalk, one channel undriven
(Waveform: Sine, Generator Level: 2 Vrms, DC Offset: 0.0V, Frequency: 1 kHz, Low-pass Filter: 20kHz, Weighting Filter: A-wt. High-pass Filter: 20Hz)	-109	dB
