DA2100 DA2200 DA2300 DA2550 DA2750 DA2950
8518400090
Specifications
| Model | DA2100 | DA2200 | DA2300 | DA2550 | DA2750 | DA2950 | |
| Rated power(TA 1KHz THD≤0.5%) | 8Ω/ stereo | 2×100W | 2×200W | 2×300W | 2×550W | 2×750W | 2×950W |
| 4Ω/ stereo | 2×200W | 2×300W | 2×450W | 2×800W | 2×1300W | 2×1600W | |
| 8Ω/ bridged | 1×300W | 1×600W | 1×900W | 1×1800W | 1×2900W | 1×3600W | |
| Distortion（Typilcal） | 1KHz | ＜0.1% | |||||
| Frequency response | 20Hz - 20 kHz | ±0.5dB | ±1dB | ||||
| Input impedance | 20KHz(Balance) ，10KHz(Un-Balance) | ||||||
| Damping factor | 5Hz-1KHz | ＞200 | ＞250 | ||||
| S/N ratio | (a-w rms) | ≥100dB | ≥95dB | ||||
| Power supply | 50~60 Hz | 110V/230VAC | PFC:90~240VAC | ||||
| Protection:Soft start, DC, VHF,AC,Over heat,over load, Limiter,Short Circuit | |||||||
| dimension(W×H×D) | 483×44×160mm | 483×44×200mm | |||||
| Net weight | 3.2kg | 4.5kg | |||||
