CSM002
8518100090
| Model No. | CSM002 |
| Element: | Pressure Gradient Transducer |
| Polar Pattern: | Uni-directional |
| Frequency Response: | 20Hz-20KHz |
| Sensitivity (0dB=1V/Pa @1KHz): | -34dB±2dB |
| Output Impedance: | 100Ω±20%(@1KHz) |
| Load Impedance: | ≥1000Ω |
| Self Noise: | 14dB A |
| Max. Input SPL: | 130dB (@1kHz≤1%T.H.D) |
| S/N Ratio: | 80dB |
| Phantom Power Requirement: | 48V Phantom Power |
| Current Consumption: | 3mA |
| Body Dimensions: | φ25x160mm |
| Net Weight: | 240g |
| Model No. | CSM002 |
| Element: | Pressure Gradient Transducer |
| Polar Pattern: | Uni-directional |
| Frequency Response: | 20Hz-20KHz |
| Sensitivity (0dB=1V/Pa @1KHz): | -34dB±2dB |
| Output Impedance: | 100Ω±20%(@1KHz) |
| Load Impedance: | ≥1000Ω |
| Self Noise: | 14dB A |
| Max. Input SPL: | 130dB (@1kHz≤1%T.H.D) |
| S/N Ratio: | 80dB |
| Phantom Power Requirement: | 48V Phantom Power |
| Current Consumption: | 3mA |
| Body Dimensions: | φ25x160mm |
| Net Weight: | 240g |
