CS55 CS65 CS85
| Specification | CS55 | CS65 | CS85 |
| Woofer : LF Unit | 5.25“ x 1 | 6.5″ x 1 | 8″ x 1 |
| Material: Graphite Cone, Rubber Surround | |||
| Tweeter : HF Driver | 0.75" x1 | 1“ x 1 | |
| Material: Aluminum dome | 1″ Titanium dome | ||
| Impedance(AC) : | 8Ω | ||
| Sensitivity( Output SPL) | 86±3dB | 87±3dB | 88±3dB |
| Frequency Range+/-3 (Freq.Range) | 62Hz~20KHz±3dB | 47Hz~20KHz±3dB | 39Hz~20KHz±3dB |
| Power Handling RMS | 60 W program , 30 W ( IEEE 219 ) | 60W program ,40W(IEEE 219 ) | 80W program ,50W(IEEE 219 ) |
| Termination : | Standard pressed connector | ||
| Taps(Transformer power) : | NA | ||
| Cut out diameter ( For Ceiling Speakers only) | 7.14"(181.5mm) | 7.67" (195mm) | 9.84” (250mm) |
| Attachment | Low-profile grille | ||
| Housing Material : | ABS | ||
| Dimension(H*W*D) | 105*196.5*196.5mm | 105.5*230*230mm | 121.3*273*273mm |
| Specification | CS55 | CS65 | CS85 |
| Woofer : LF Unit | 5.25“ x 1 | 6.5″ x 1 | 8″ x 1 |
| Material: Graphite Cone, Rubber Surround | |||
| Tweeter : HF Driver | 0.75" x1 | 1“ x 1 | |
| Material: Aluminum dome | 1″ Titanium dome | ||
| Impedance(AC) : | 8Ω | ||
| Sensitivity( Output SPL) | 86±3dB | 87±3dB | 88±3dB |
| Frequency Range+/-3 (Freq.Range) | 62Hz~20KHz±3dB | 47Hz~20KHz±3dB | 39Hz~20KHz±3dB |
| Power Handling RMS | 60 W program , 30 W ( IEEE 219 ) | 60W program ,40W(IEEE 219 ) | 80W program ,50W(IEEE 219 ) |
| Termination : | Standard pressed connector | ||
| Taps(Transformer power) : | NA | ||
| Cut out diameter ( For Ceiling Speakers only) | 7.14"(181.5mm) | 7.67" (195mm) | 9.84” (250mm) |
| Attachment | Low-profile grille | ||
| Housing Material : | ABS | ||
| Dimension(H*W*D) | 105*196.5*196.5mm | 105.5*230*230mm | 121.3*273*273mm |
